Celduc 75 A Solid State Relay, Random, Chassis Mount, Thyristor, 520 V ac Maximum Load [SGT767470E]; 776-7700
by Celduc
0₫
Mã kho: 7767700
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Minimum Load Current | 1 mA |
| Maximum Load Current | 75 A |
| Mounting Type | Panel Mount |
| Minimum Load Voltage | 24 V ac |
| Maximum Load Voltage | 520 V ac |
| Minimum Control Voltage | 4 V dc |
| Maximum Control Voltage | 32 V dc |
| Switching Type | Random |
| Output Device | Thyristor |
| Maximum Turn On Time | 30 ms |
| Dimensions | 100 x 75.15 x 46mm |
| Depth | 75.15mm |
| Control Voltage Range | 4 → 32 V dc |
| Load Voltage Range | 24 → 520V ac |
| Operating Temperature Range | -40 → +100°C |
| Length | 100mm |
| Off State Leakage Current | 1 mA |
| Height | 46mm |
