Carlo Gavazzi 25 A rms Solid State Relay, Zero Crossing, Chassis Mount, Thyristor, 265 V Maximum Load [RM1A23D25]; 479-0347
0₫
Mã kho: 4790347
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Minimum Load Current | 150 mA |
| Maximum Load Current | 25 A rms |
| Mounting Type | Panel Mount |
| Maximum Load Voltage | 265 V |
| Maximum Control Voltage | 32 V |
| Switching Type | Zero Crossing |
| Output Device | Thyristor |
| Dimensions | 44.8 x 58.2 x 28.8mm |
| Length | 44.8mm |
| Minimum Operating Temperature | -20°C |
| Load Voltage Range | 24 → 265V ac |
| Height | 28.8mm |
| Depth | 58.2mm |
| Operating Temperature Range | -20 → +70°C |
| Maximum Operating Temperature | +70°C |
| Control Voltage Range | 3 → 32 V dc |
