| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Minimum Load Current | 1.2 A |
| Maximum Load Current | 85 A |
| Mounting Type | DIN Rail |
| Series | RGC2 |
| Minimum Load Voltage | 42 V ac |
| Maximum Load Voltage | 660 V ac |
| Minimum Control Voltage | 5 V dc |
| Maximum Control Voltage | 32 V dc |
| Switching Type | Zero Crossing |
| Terminal Type | Box Clamp |
| Output Device | Varistor |
| Maximum Turn On Time | 1 s |
| Dimensions | 72 x 141 x 141mm |
| Relay Type | Solid State Relay |
| Special Features | Heat Sinked |
| Depth | 141mm |
| Load Voltage Range | 42 → 600V ac |
| Control Voltage Range | 5 → 32 V dc |
| Height | 141mm |
| Minimum Operating Temperature | -40°C |
| Operating Temperature Range | -40 → +70°C |
| Length | 72mm |
| Off State Leakage Current | 5 mA |
| Maximum Operating Temperature | +70°C |
| Number of Poles | 2 |
