| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Minimum Load Current | 150 mA |
| Maximum Load Current | 20 A |
| Mounting Type | DIN Rail |
| Series | RG..M |
| Minimum Load Voltage | 42 V ac |
| Maximum Load Voltage | 265 V ac |
| Minimum Control Voltage | 4 V dc |
| Maximum Control Voltage | 32 V dc |
| Switching Type | Zero Crossing |
| Terminal Type | Screw |
| Output Device | Varistor |
| Dimensions | 17.8 x 134 x 110mm |
| Height | 110mm |
| Load Voltage Range | 42 → 265V ac |
| Special Features | Alarm Transistor Output, Integrated Monitoring |
| Operating Temperature Range | -20 → +65°C |
| Control Voltage Range | 4 → 32 V dc |
| Minimum Operating Temperature | -20°C |
| Depth | 134mm |
| Length | 17.8mm |
| Maximum Operating Temperature | +65°C |
| Off State Leakage Current | <5 mA |
| Number of Poles | 1 |
| Relay Type | Solid State Relay |
