Burkert Solenoid Valve 143492, 2 port , NO, 230 V ac, 1/4in [143492]; 337-5565
by Burkert
0₫
Mã kho: 3375565
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Supply Voltage | 230 V ac |
| Number of Ports | 2 |
| Connection | 1/4 in G Female |
| Connection Size | 1/4in |
| Default Valve Position | NO |
| Suitable Applications | Compressed Air, Gas, Hydraulic Oil, Neutral Liquid |
| Type | 43863 |
| Orifice Diameter | 2.5mm |
| Body Material | Brass |
| Maximum Working Pressure | 8 bar |
| Operating Temperature Range | -10 → +55 °C |
| Minimum Operating Temperature | -10°C |
| Maximum Operating Temperature | +55°C |
| Series | 211 |
| Thread Standard or Connection Type | G |
| Connection Gender | Female |
| Flow Factor Kv | 0.16m³/h |
