Copal Electronics, 5 Position DP Rotary Switch, 500 mA @ 125 V ac [MR2-5-Z]; 225-571
0₫
Mã kho: 225571
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Contact Configuration | DP |
Contact Current Rating | 500 mA @ 125 V ac |
Number of Switch Positions | 5 |
Number of Contacts | 2 |
Voltage Rating | 125V ac |
Depth | 16mm |
Width | 16mm |
Mounting Type | Panel Mount |
Minimum Operating Temperature | -20°C |
Contact Material | Silver Plated |
Angle of Throw | 36° |
Height | 40.8mm |
Maximum Operating Temperature | +85°C |
