![C & K A11442MNZB 1558817](http://nguyenxuong.com/cdn/shop/products/Y1558817-01_240x350.jpg?v=1594050963)
C & K, 2 Position SPDT Rotary Switch, 2.5 A @ 125 V ac, 350 mA @ 125 V dc, Solder Lug [A11442MNZB]; 155-8817
by C & K
0₫
Mã kho: 1558817
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Contact Configuration | SPDT |
Contact Current Rating | 2.5 A @ 125 V ac, 350 mA @ 125 V dc |
Number of Switch Positions | 2 |
Number of Contacts | 2 |
Voltage Rating | 125V ac/dc |
Diameter | 26.19mm |
Dimensions | 26.19 (Dia.) x 58.94mm |
Mounting Type | Panel Mount |
Mounting Hole Size | 10.21 mm |
Terminal Type | Solder Lug |
Contact Material | Brass (Stationary, Coin Silver (Movable), Terminal) |
Maximum Operating Temperature | +85°C |
Actuator Colour | Black |
Height | 58.94mm |
Standards Met | CULus Recognised, UL 94 V-0 |
Contact Type | Non-Shorting |
Case Material | Glass Filled Nylon 6/6 |
Angle of Throw | 90° |
Minimum Operating Temperature | -30°C |
