TE Connectivity PIDG Series Insulated Crimp Ring Terminal, M3.5 (#6) Stud Size, 0.1mm² to 0.4mm² Wire Size, Yellow [323011]; 161-8620
0₫
Mã kho: 1618620
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Series | PIDG |
| Insulation | Insulated |
| Insulation Material | Nylon |
| Outer Ring Diameter | 6.35mm |
| Minimum Wire Size mm² | 0.1mm² |
| Maximum Wire Size mm² | 0.4mm² |
| Minimum Wire Size AWG | 26AWG |
| Maximum Wire Size AWG | 22AWG |
| Stud Size | M3.5 (#6) |
| Colour | Yellow |
| Contact Material | Copper |
| Contact Plating | Tin |
| Thickness | 0.46mm |
| Overall Length | 18.26mm |
