Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Maximum Resistance | 3.5kΩ |
| Tolerance | ±10% |
| Power Rating | 50W |
| Number of Turns | 300 ° |
| Mounting Type | Panel Mount |
| Shaft Diameter | 6.35 mm |
| Termination Style | Solder Lug |
| Dimensions | 58.67 (Dia.) x 34.93mm |
| Length | 34.93mm |
| Maximum Voltage Rating | 750 Vrms |
| Electrical Taper | Linear |
| Current Rating | 110mA |
| Shaft Length | 8.73mm |
| Core Type | Open |
| Actuator Type | Linear Shaft |
