Vishay Bussed Resistor Network 10kΩ ±2% 15 Resistors, 1.92W Total, DIP package MDP Solder [MDP160110K0GE04]; 852-4769
by Vishay
0₫
Mã kho: 8524769
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Resistance | 10 kΩ |
| Series | MDP |
| Number of Resistors | 15 |
| Tolerance | ±2% |
| Power Rating | 1.92W |
| Power Rating per Resistor | 0.12W |
| Package/Case | DIP |
| Case Style | Moulded |
| Circuit Designator | BUS |
| Temperature Coefficient | ±100ppm/°C |
| Termination Style | Solder |
| Dimensions | 21.59 x 6.35 x 3.81mm |
| Depth | 6.35mm |
| Height | 3.81mm |
| Length | 21.59mm |
| Maximum Operating Temperature | +125°C |
| Minimum Operating Temperature | -55°C |
