Vishay Voltage Divider Resistor Network 9 kΩ, 9 MΩ, 90 kΩ, 100 Ω, 900 kΩ, 900 Ω ±0.1% 6 Resistors, 0.6W Total, [CNS471A6]; 346-8538
by Vishay
0₫
Mã kho: 3468538
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Resistance | 9 kΩ, 9 MΩ, 90 kΩ, 100 Ω, 900 kΩ, 900 Ω |
| Series | CNS 471 |
| Number of Resistors | 6 |
| Tolerance | ±0.1% |
| Power Rating | 0.6W |
| Power Rating per Resistor | 0.1W |
| Package/Case | SIP |
| Case Style | Conformal |
| Circuit Designator | VOLT/D |
| Temperature Coefficient | ±25ppm/°C |
| Dimensions | 2.54 x 7 x 21.08mm |
| Termination Style | Pin |
| Depth | 2.54mm |
| Height | 7mm |
| Length | 21.08mm |
| Maximum Operating Temperature | +70°C |
| Minimum Operating Temperature | 0°C |
| Number of Terminals | 7 |
