KOA CND Series 1kΩ ±5% Bussed Array Resistor, 10 Resistors 1206 package Concave SMT [CND1J10YTTD102J]; 172-8948
by KOA
0₫
Mã kho: 1728948
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Resistance | 1 kΩ |
| Number of Resistors | 10 |
| Package/Case | 1206 (3216M) |
| Termination Style | Concave SMT |
| Tolerance | ±5% |
| Power Rating per Resistor | 0.05W |
| Circuit Designator | BUS |
| Length | 3.2mm |
| Depth | 1.6mm |
| Height | 0.55mm |
| Dimensions | 3.2 x 1.6 x 0.55mm |
| Series | CND |
| Number of Terminals | 20 |
| Maximum Operating Temperature | +125°C |
| Temperature Coefficient | ±200ppm/°C |
| Minimum Operating Temperature | -55°C |
