Bourns Isolated Resistor Network 47kΩ ±2% 5 Resistors, 1.25W Total, SIP package 4600X Pin [4610X-102-473LF]; 865-2019
by Bourns
0₫
Mã kho: 8652019
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Resistance | 47 kΩ |
Number of Resistors | 5 |
Package/Case | SIP |
Power Rating | 1.25W |
Termination Style | Pin |
Tolerance | ±2% |
Case Style | Conformal |
Power Rating per Resistor | 0.3W |
Circuit Designator | ISOL |
Length | 25.35mm |
Depth | 2.49mm |
Height | 5.08mm |
Dimensions | 25.35 x 2.49 x 5.08mm |
Series | 4600X |
Maximum Operating Temperature | +125°C |
Minimum Operating Temperature | -55°C |
Temperature Coefficient | ±100ppm/°C |
