Bourns 4600X Series 560Ω ±2% Bussed Resistor Network, 7 Resistors, 1W total SIP package Pin [4608X-101-561LF]; 865-1952
by Bourns
0₫
Mã kho: 8651952
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Resistance | 560 Ω |
Number of Resistors | 7 |
Package/Case | SIP |
Power Rating | 1W |
Termination Style | Pin |
Tolerance | ±2% |
Case Style | Conformal |
Power Rating per Resistor | 0.2W |
Circuit Designator | BUS |
Length | 20.27mm |
Depth | 2.49mm |
Height | 5.08mm |
Dimensions | 20.27 x 2.49 x 5.08mm |
Series | 4600X |
Temperature Coefficient | ±100ppm/°C |
Minimum Operating Temperature | -55°C |
Maximum Operating Temperature | +125°C |
