Bourns 4300R Series 1kΩ ±2% Bussed Resistor Network, 9 Resistors, 1.25W total SIP package Pin [4310R-101-102LF]; 161-7174
by Bourns
0₫
Mã kho: 1617174
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Resistance | 1 kΩ |
Number of Resistors | 9 |
Package/Case | SIP |
Power Rating | 1.25W |
Termination Style | Pin |
Tolerance | ±2% |
Case Style | Moulded |
Power Rating per Resistor | 0.2W |
Circuit Designator | BUS |
Length | 19.92mm |
Depth | 2.16mm |
Height | 4.95mm |
Dimensions | 19.92 x 2.16 x 4.95mm |
Series | 4300R |
Temperature Coefficient | ±100ppm/°C |
Maximum Operating Temperature | +125°C |
Minimum Operating Temperature | -55°C |
