Bourns Bussed Resistor Network 100kΩ ±2% 8 Resistors, 1.13W Total, SIP package 4300R Through Hole [4309R-101-104LF]; 161-7165
by Bourns
0₫
Mã kho: 1617165
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Series | 4300R |
| Resistance | 100 kΩ |
| Number of Resistors | 8 |
| Tolerance | ±2% |
| Power Rating | 1.13W |
| Power Rating per Resistor | 0.2W |
| Package/Case | SIP |
| Case Style | Moulded |
| Circuit Designator | BUS |
| Temperature Coefficient | ±100ppm/°C |
| Dimensions | 22.45 x 2.16 x 4.95mm |
| Termination Style | Through Hole |
| Depth | 2.16mm |
| Height | 4.95mm |
| Length | 22.45mm |
| Maximum Operating Temperature | +125°C |
| Minimum Operating Temperature | -55°C |
| Number of Terminals | 9 |
