Double Pole Single Throw (DPST) Latching Push Button Switch, 26.19 x 16.5mm, Through Hole [V80102MS02QE]; 176-9443
by C & K
0₫
Mã kho: 1769443
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Switch Operation | Latching |
| Mounting Type | Through Hole |
| Illuminated | No |
| Contact Configuration | Double Pole Single Throw (DPST) |
| Panel Cut Out Size | 26.19 x 16.5mm |
| Contact Current Rating | 4 (DC) A, 10 (AC) A |
| Terminal Type | PC Pin |
| Contact DC Voltage Rating | 30V |
| Contact AC Voltage Rating | 125V |
| Actuator Type | Lever |
| Case Colour | Black |
