Microchip Technology MIC1832MY, Voltage Detector IC 2.47V, WDT, Reset Input 8-Pin, SOIC [MIC1832MY]; 177-0684
by Microchip
0₫
Mã kho: 1770684
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Number of Supervisors | 1 |
| Output Driver | Push-Pull |
| Watchdog Timer | Yes |
| Power Fail Detection | Yes |
| Nominal Monitored Voltage | 2.55V |
| Mounting Type | Surface Mount |
| Package Type | SOIC |
| Pin Count | 8 |
| Manual Reset | Yes |
| Battery Backup Switching | Yes |
| Maximum Reset Active Time | 1000ms |
| Dimensions | 0.19 x 0.15 x 0.05in |
| Height | 1.27mm |
| Minimum Monitored Voltage | 2.47V |
| Maximum Operating Temperature | +85 °C |
| Maximum Operating Supply Voltage | 5.5 V |
| Width | 3.81mm |
| Maximum Monitored Voltage | 2.64V |
| Minimum Operating Supply Voltage | 1.4 V |
| Minimum Operating Temperature | -40 °C |
| Length | 4.83mm |
