Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| AC or DC Input Voltage | Ac, Dc |
| AC or DC Output Voltage | Dc |
| Input Voltage | 85 → 264 V ac, 120 → 370 V dc |
| Output Voltage | 24 V |
| Output Current | 4.2 A |
| Power Rating | 100.8W |
| Number of Outputs | 1 |
| Type | Power Supply |
| Height | 58mm |
| Mounting Type | DIN Rail Mount |
| Load Regulation | ±1.5 (Typ.)% |
| Output Voltage Adjustment Range | 21.6 → 29V |
| Maximum Temperature | +70°C |
| MTBF | >300000h |
| Depth | 92.66mm |
| Minimum Temperature | -40°C |
| Efficiency | 90 (Typ.)% |
| Ripple And Noise | 150mV |
