| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Output Voltage | 1.22 → 5 V |
| Output Type | Adjustable |
| Package Type | D2PAK (TO-263) |
| Maximum Output Current | 3A |
| Mounting Type | Surface Mount |
| Minimum Input Voltage | 2.8 V |
| Maximum Input Voltage | 5.5 V |
| Pin Count | 5 |
| Number of Outputs | 1 |
| Polarity | Positive |
| Quiescent Current | 0.125mA |
| Minimum Operating Temperature | -40 °C |
| Maximum Operating Temperature | +125 °C |
| Length | 10.16mm |
| Line Regulation | 0.04 %/V |
| Reference Voltage | 1.224V |
| Height | 4.58mm |
| Dimensions | 10.16 x 8.42 x 4.58mm |
| Enable | Yes |
| Width | 8.42mm |
| Load Regulation | 0.35 %/V |
