ON Semiconductor MC7815BTG Linear Voltage Regulator, 1A, 15 V, ±4% 3-Pin, TO-220 [MC7815BTG]; 145-2789
0₫
Mã kho: 1452789
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Output Voltage | 15 V |
| Maximum Output Current | 1A |
| Package Type | TO-220 |
| Output Type | Fixed |
| Mounting Type | Through Hole |
| Maximum Input Voltage | 35 V |
| Pin Count | 3 |
| Minimum Operating Temperature | -40 °C |
| Maximum Operating Temperature | +125 °C |
| Number of Outputs | 1 |
| Polarity | Positive |
| Accuracy | ±4% |
| Typical Dropout Voltage @ Current | 2 V @ 1 A |
| Dimensions | 10.28 x 4.82 x 30.02mm |
| Quiescent Current | 3.5mA |
| Width | 4.82mm |
| Series | MC78xx |
| Height | 30.02mm |
| Length | 10.28mm |
| Line Regulation | 300 mV |
| Load Regulation | 300 mV |
