Analog Devices ADP7182ACPZ-R7, Low Noise LDO Voltage Regulator, -200mA Adjustable, -27 → -1.2 V, -1.244V 8-Pin [ADP7182ACPZ-R7]; 160-3382
0₫
Mã kho: 1603382
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Output Voltage | -27 → -1.2 V |
| Output Type | Adjustable |
| Package Type | LFCSP |
| Maximum Output Current | -200mA |
| Mounting Type | Surface Mount |
| Minimum Input Voltage | -2.7 V |
| Maximum Input Voltage | -28 V |
| Pin Count | 8 |
| Number of Outputs | 1 |
| Polarity | Negative |
| Quiescent Current | -650µA |
| Accuracy | -1.244V |
| Minimum Operating Temperature | -40 °C |
| Maximum Operating Temperature | +125 °C |
| Reference Voltage | -1.22V |
| Height | 0.75mm |
| Length | 3.1mm |
| Dimensions | 3.1 x 3.1 x 0.75mm |
| Load Regulation | 0.006 %/mA |
| Enable | Yes |
| Line Regulation | 0.01 %/V |
| Width | 3.1mm |
