Schurter FMAD CEE Series 32A 415 V ac 50 Hz, 60 Hz Screw Mount Power Line Filter, with Screw Terminals 3 Phase [FMAD-T4QT-3260.EU]; 126-2194
by Schurter
0₫
Mã kho: 1262194
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Maximum Current Rating | 32A |
| Maximum Voltage Rating | 415 V ac |
| Mounting Type | Screw Mount |
| Termination Style | Screw |
| Number of Phases | 3 |
| Series | FMAD CEE |
| Number of Stages | Single Stage |
| Operating Frequency | 50 Hz, 60 Hz |
| Length | 111mm |
| Depth | 195mm |
| Height | 81mm |
| Dimensions | 111 x 195 x 81mm |
| Leakage Current | 10 mA |
| Minimum Operating Temperature | -40°C |
| Maximum Operating Temperature | +85°C |
| Power Loss | 4.9W |
