EPCOS B84771 Series 6A 250 V ac/dc 50 → 60Hz Panel Mount RFI Filter, with Tab Terminals, Single Phase [B84771C0006A000]; 780-4988
by EPCOS
0₫
Mã kho: 7804988
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Maximum Current Rating | 6A |
Maximum Voltage Rating | 250 V ac/dc |
Mounting Type | Panel Mount |
Termination Style | Tab |
Number of Phases | 1 |
Series | B84771 |
Operating Frequency | 50 → 60Hz |
Length | 50mm |
Depth | 43.5mm |
Height | 22.5mm |
Capacitance | 0.1 x 1 μF, 2200 x 2 pF |
Inductance | 0.84 x 2 mH |
Dimensions | 50 x 43.5 x 22.5mm |
Leakage Current | 0.173 mA |
Minimum Operating Temperature | -25°C |
Maximum Operating Temperature | +85°C |
Standards Met | UL 1283 |
