EPCOS B84112G Series 12A 250 V ac/dc 50 → 60Hz Chassis Mount EMI Filter, with Tab Terminals, Single Phase [B84112G0000B112]; 166-0215
by EPCOS
0₫
Mã kho: 1660215
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Maximum Current Rating | 12A |
| Maximum Voltage Rating | 250 V ac/dc |
| Mounting Type | Chassis Mount |
| Termination Style | Tab |
| Number of Phases | 1 |
| Series | B84112G |
| Number of Stages | Single Stage |
| Operating Frequency | 50 → 60Hz |
| Length | 84.7mm |
| Depth | 52mm |
| Capacitance | 0.68 x 2 μF, 4700 x 2 pF |
| Height | 29mm |
| Inductance | 1.6 x 2 mH |
| Dimensions | 84.7 x 52 x 29mm |
| Leakage Current | 0.369 mA |
| Minimum Operating Temperature | -25°C |
| Maximum Operating Temperature | +100°C |
