EPCOS B84112G Series 2A 250 V ac/dc 50 → 60Hz Chassis Mount EMI Filter, with Tab Terminals, Single Phase [B84112G0000B020]; 166-0206
by EPCOS
0₫
Mã kho: 1660206
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Maximum Current Rating | 2A |
| Maximum Voltage Rating | 250 V ac/dc |
| Mounting Type | Chassis Mount |
| Termination Style | Tab |
| Number of Phases | 1 |
| Series | B84112G |
| Number of Stages | Single Stage |
| Operating Frequency | 50 → 60Hz |
| Length | 72mm |
| Depth | 46mm |
| Capacitance | 0.1 x 25 μF, 4700 x 2 pF |
| Height | 26mm |
| Dimensions | 72 x 46 x 26mm |
| Inductance | 12 x 2 mH |
| Minimum Operating Temperature | -25°C |
| Leakage Current | 0.369 mA |
| Maximum Operating Temperature | +100°C |
