SMC Vacuum Switch, R 1/8 0kPa to 101 kPa, 500 kPa [ZSE30A-01-N]; 792-7895
by SMC
0₫
Mã kho: 7927895
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Minimum Operating Pressure | 0kPa |
| Maximum Operating Pressure | 101 kPa, 500 kPa |
| Pressure Type | Vacuum |
| Suitable Media | Air, Non Corrosive Gas, Non Flammable Gas |
| Connection | R 1/8 |
| Type | NPN Open Collector |
| Voltage Rating | 12 → 24V dc |
| Connection Thread Size | 1/8 in |
| Manufacturer Series | ZSE |
| Connection Thread Standard | R |
| Minimum Operating Temperature | 0°C |
| Maximum Operating Temperature | +50°C |
| IP Rating | IP40 |
| LED Indicator | Yes |
