Pepperl + Fuchs Background Suppression Photoelectric Sensor 10 → 350 mm Detection Range Push Pull IP67, IP69K [ML7-8-H-350-IR/59/65a/136/143]; 891-9501
0₫
Mã kho: 8919501
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Sensor Style | Block |
| Detection Type | Background Suppression |
| Detection Range | 10 → 350 mm |
| Output Type | Push Pull |
| Electrical Connection | 4-Pin M8 Connector |
| Maximum DC Voltage | 30V |
| Terminal Type | M8 Connector |
| Light Source | Infrared |
| IP Rating | IP67, IP69K |
| Maximum Current | <20 mA |
| Response Time | 2 ms |
| Housing Material | PC |
| Minimum Operating Temperature | -20°C |
| Series | ML7 |
| Standards Met | AWM/STYLE 2464 80 C /300VRMS CM 75C c(UL) Type CMG 60C, CE, CULus, ECOLAB, VISC |
| Mounting Type | Threaded |
| Maximum Operating Temperature | +60°C |
