TE Connectivity, AMPMODU System 50, 10 Way, 2 Row, Vertical PCB Header [5-104549-1]; 906-0840
0₫
Mã kho: 9060840
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Series | AMPMODU System 50 |
| Pitch | 1.27mm |
| Number of Contacts | 10 |
| Number of Rows | 2 |
| Body Orientation | Vertical |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Board to Board, Wire to Board |
| Mounting Type | Surface Mount |
| Termination Method | Solder |
| Contact Plating | Gold |
| Contact Material | Copper Alloy |
| Current Rating | 1A |
