Hirose, A3B, 12 Way, 2 Row, Right Angle PCB Header [A3B-12PA-2DS(51)]; 172-1794
by Hirose
0₫
Mã kho: 1721794
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Series | A3B |
| Pitch | 2mm |
| Number of Contacts | 12 |
| Number of Rows | 2 |
| Body Orientation | Right Angle |
| Shrouded/Unshrouded | Unshrouded |
| Mounting Type | Through Hole |
| Connector System | Wire to Board |
| Termination Method | Solder |
| Contact Material | Brass |
| Contact Plating | Gold |
| Current Rating | 1A |
