TE Connectivity DPNO Non-Latching Relay PCB Mount, 12V dc Coil, 30 A [T92P7D12-12=T92]; 680-2653
0₫
Mã kho: 6802653
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Coil Voltage | 12 V dc |
| Coil Resistance | 86 Ω |
| Contact Configuration | DPNO |
| Mounting Type | PCB Mount |
| Switching Current | 30A |
| Terminal Type | Through Hole |
| Number of Poles | 2 |
| Maximum Switching Power AC | 1.25 kVA |
| Height | 30.73mm |
| Series | T92 |
| Length | 52.32mm |
| Depth | 34.54mm |
