Panasonic DPNO Non-Latching Relay PCB Mount, 12V dc Coil, 20 A Non-Latching Relay [HEV2aNP12v]; 134-7859
by Panasonic
0₫
Mã kho: 1347859
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Coil Voltage | 12 V dc |
| Coil Power | 1.92W |
| Coil Resistance | 75 Ω |
| Isolation Coil To Contact | 5000Vrms |
| Contact Configuration | DPNO |
| Mounting Type | PCB Mount |
| Switching Current | 20A |
| Terminal Type | PCB Pin |
| Number of Poles | 2 |
| Maximum Switching Voltage DC | 1000V |
| Length | 50mm |
| Height | 39.4mm |
| Standards Met | CULus, VDE |
| Depth | 41mm |
