Panasonic DPNO Non-Latching Relay PCB Mount, 24V dc Coil, 20 A [HEV2AN-P-DC24V]; 811-3539
by Panasonic
0₫
Mã kho: 8113539
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Coil Voltage | 24 V dc |
| Coil Power | 1.92W |
| Coil Resistance | 300 Ω |
| Isolation Coil To Contact | 5kV rms |
| Contact Configuration | DPNO |
| Mounting Type | PCB Mount |
| Switching Current | 20A |
| Maximum Switching Voltage DC | 1000V |
| Height | 39.4mm |
| Depth | 41mm |
| Series | HE-V |
| Length | 50mm |
