Omron SPNO Non-Latching Relay PCB Mount, 12V dc Coil, 10 A [G6RL1AASI12DC]; 683-9778
by Omron
0₫
Mã kho: 6839778
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Coil Voltage | 12 V dc |
Coil Power | 220mW |
Coil Resistance | 654 Ω |
Isolation Coil To Contact | 5kV ac |
Contact Configuration | SPNO |
Mounting Type | PCB Mount |
Switching Current | 10A |
Terminal Type | Through Hole |
Maximum Switching Power DC | 150 W |
Depth | 10mm |
Height | 12.3mm |
Length | 28.5mm |
Maximum Switching Power AC | 2.5 kVA |
Series | G6RL |
