3 Pole Surface Mount Emergency Stop Push Button, NO/NC, 63 A, 30 kW, IP65 [P3-63/I4-SI/HI11]; 180-9317
by Eaton
0₫
Mã kho: 1809317
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Number of Poles | 3 |
| Range | Safety Switch |
| Maximum Current | 63 A |
| Model Number | P3-63/I4-SI/HI11 |
| Series | P3 |
| Mounting Type | Surface Mount |
| Normal State Configuration | NO/NC |
| Power Rating | 30 kW |
| IP Rating | IP65 |
| Accepts Padlocks | Yes |
| Voltage Rating | 690 V ac |
| Auxiliary Contacts Available | Yes |
| Switch Rating | 800 A |
| Length | 160mm |
| Width | 139mm |
| Depth | 240mm |
| Terminal Type | Screw |
| Minimum Operating Temperature | -25°C |
| Handle Colour | Red |
| Maximum Operating Temperature | +40°C |
| Throw Configuration | NO/NC |
