4 Pole DIN Rail Switch Disconnector, 4NO, 32 A, IP20, IP40 [SD204/32]; 175-5097
by ABB
0₫
Mã kho: 1755097
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Number of Poles | 4 |
| Range | Pro M Compact |
| Maximum Current | 32 A |
| Mounting Type | DIN Rail |
| Series | SD204 |
| Normal State Configuration | 4NO |
| IP Rating | IP20, IP40 |
| Accepts Padlocks | Yes |
| Voltage Rating | 440 V ac |
| Auxiliary Contacts Available | Yes |
| Length | 70mm |
| Width | 69mm |
| Depth | 88mm |
| Terminal Type | Screw |
| Minimum Operating Temperature | -25°C |
| Maximum Operating Temperature | +55°C |
| Throw Configuration | 4PST |
