SI7309DN-T1-E3 P-Channel MOSFET, 3.9 A, 60 V, 8-Pin PowerPAK 1212 Vishay [SI7309DN-T1-E3]; 165-2765
by Vishay
0₫
Mã kho: 1652765
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Channel Type | P |
Maximum Continuous Drain Current | 3.9 A |
Maximum Drain Source Voltage | 60 V |
Package Type | PowerPAK 1212 |
Mounting Type | Surface Mount |
Pin Count | 8 |
Maximum Drain Source Resistance | 115 mΩ |
Channel Mode | Enhancement |
Minimum Gate Threshold Voltage | 1V |
Maximum Power Dissipation | 3.2 W |
Transistor Configuration | Single |
Maximum Gate Source Voltage | -20 V, +20 V |
Number of Elements per Chip | 1 |
Height | 1.04mm |
Width | 3.05mm |
Transistor Material | Si |
Minimum Operating Temperature | -65 °C |
Maximum Operating Temperature | +150 °C |
Typical Gate Charge @ Vgs | 14.5 nC @ 10 V |
Length | 3.05mm |
