![Vishay IRFD9014PBF 1780919](http://nguyenxuong.com/cdn/shop/products/RBIPOLAR-08_d6e1b210-afcf-4570-abde-5ed3d45de5e4_310x342.jpg?v=1594084099)
IRFD9014PBF P-Channel MOSFET, 1.1 A, 60 V, 4-Pin HVMDIP Vishay [IRFD9014PBF]; 178-0919
by Vishay
0₫
Mã kho: 1780919
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Channel Type | P |
Maximum Continuous Drain Current | 1.1 A |
Maximum Drain Source Voltage | 60 V |
Package Type | HVMDIP |
Mounting Type | Through Hole |
Pin Count | 4 |
Maximum Drain Source Resistance | 500 mΩ |
Channel Mode | Enhancement |
Minimum Gate Threshold Voltage | 2V |
Maximum Power Dissipation | 1.3 W |
Transistor Configuration | Single |
Maximum Gate Source Voltage | -20 V, +20 V |
Number of Elements per Chip | 1 |
Maximum Operating Temperature | +175 °C |
Typical Gate Charge @ Vgs | 12 nC @ 10 V |
Height | 3.37mm |
Width | 6.29mm |
Transistor Material | Si |
Minimum Operating Temperature | -55 °C |
Length | 5mm |
