![Toshiba TK31J60W,S1VQ(O 7995093](http://nguyenxuong.com/cdn/shop/products/R7995093-01_198x444.jpg?v=1594109228)
TK31J60W,S1VQ(O N-Channel MOSFET, 31 A, 600 V DTMOSIV, 3-Pin TO-3PN Toshiba [TK31J60W,S1VQ(O]; 799-5093
by Toshiba
0₫
Mã kho: 7995093
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Channel Type | N |
Maximum Continuous Drain Current | 31 A |
Maximum Drain Source Voltage | 600 V |
Package Type | TO-3PN |
Mounting Type | Through Hole |
Pin Count | 3 |
Maximum Drain Source Resistance | 88 mΩ |
Channel Mode | Enhancement |
Maximum Gate Threshold Voltage | 3.7V |
Maximum Power Dissipation | 230 W |
Transistor Configuration | Single |
Maximum Gate Source Voltage | -30 V, +30 V |
Number of Elements per Chip | 1 |
Maximum Operating Temperature | +150 °C |
Series | DTMOSIV |
Transistor Material | Si |
Width | 4.5mm |
Height | 20mm |
Length | 15.5mm |
Typical Gate Charge @ Vgs | 86 nC @ 10 V |
