TK15A20D,S4X(S N-Channel MOSFET, 15 A, 200 V, 3-Pin SC-67 Toshiba [TK15A20D,S4X(S]; 756-3375
by Toshiba
0₫
Mã kho: 7563375
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Channel Type | N |
Maximum Continuous Drain Current | 15 A |
Maximum Drain Source Voltage | 200 V |
Package Type | SC-67 |
Mounting Type | Through Hole |
Pin Count | 3 |
Maximum Drain Source Resistance | 180 mΩ |
Channel Mode | Enhancement |
Maximum Gate Threshold Voltage | 3.5V |
Maximum Power Dissipation | 35 W |
Transistor Configuration | Single |
Maximum Gate Source Voltage | -20 V, +20 V |
Number of Elements per Chip | 1 |
Width | 15mm |
Typical Gate Charge @ Vgs | 26 nC @ 10 V |
Transistor Material | Si |
Maximum Operating Temperature | +150 °C |
Height | 4.5mm |
Length | 10mm |
