TSM6968DCA RVG Dual N-Channel MOSFET, 6.5 A, 20 V, 8-Pin TSSOP Taiwan Semi [TSM6968DCA RVG]; 398-449
0₫
Mã kho: 398449
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Channel Type | N |
Maximum Continuous Drain Current | 6.5 A |
Maximum Drain Source Voltage | 20 V |
Package Type | TSSOP |
Mounting Type | Surface Mount |
Pin Count | 8 |
Maximum Drain Source Resistance | 22 mΩ |
Channel Mode | Enhancement |
Maximum Gate Threshold Voltage | 1V |
Maximum Power Dissipation | 1.04 W |
Transistor Configuration | Common Drain |
Maximum Gate Source Voltage | -12 V, +12 V |
Number of Elements per Chip | 2 |
Transistor Material | Si |
Minimum Operating Temperature | -55 °C |
Height | 1.05mm |
Maximum Operating Temperature | +150 °C |
Length | 4.5mm |
Width | 3.1mm |
Typical Gate Charge @ Vgs | 15 nC @ 4.5 V |
