![STMicroelectronics STU5N60M2 8291487](http://nguyenxuong.com/cdn/shop/products/R8291487-01_444x315.jpg?v=1594202051)
STU5N60M2 N-Channel MOSFET, 3.5 A, 650 V MDmesh M2, 3-Pin IPAK STMicroelectronics [STU5N60M2]; 829-1487
0₫
Mã kho: 8291487
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Channel Type | N |
Maximum Continuous Drain Current | 3.5 A |
Maximum Drain Source Voltage | 650 V |
Package Type | IPAK (TO-251) |
Mounting Type | Through Hole |
Pin Count | 3 |
Maximum Drain Source Resistance | 1.4 Ω |
Channel Mode | Enhancement |
Maximum Gate Threshold Voltage | 4V |
Minimum Gate Threshold Voltage | 2V |
Maximum Power Dissipation | 45 W |
Transistor Configuration | Single |
Maximum Gate Source Voltage | -25 V, +25 V |
Number of Elements per Chip | 1 |
Typical Gate Charge @ Vgs | 8.5 nC @ 10 V |
Length | 6.6mm |
Series | MDmesh M2 |
Maximum Operating Temperature | +150 °C |
Transistor Material | Si |
Height | 6.2mm |
Width | 2.4mm |
