![STMicroelectronics STU3N80K5 1688069](http://nguyenxuong.com/cdn/shop/products/R8291475-01_3c9dc913-4c5d-42e3-a672-84c5715aa737_444x315.jpg?v=1594347670)
STU3N80K5 N-Channel MOSFET, 2.5 A, 800 V MDmesh K5, SuperMESH5, 3-Pin IPAK STMicroelectronics [STU3N80K5]; 168-8069
0₫
Mã kho: 1688069
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Channel Type | N |
Maximum Continuous Drain Current | 2.5 A |
Maximum Drain Source Voltage | 800 V |
Package Type | IPAK (TO-251) |
Mounting Type | Through Hole |
Pin Count | 3 |
Maximum Drain Source Resistance | 3.5 Ω |
Channel Mode | Enhancement |
Maximum Gate Threshold Voltage | 5V |
Minimum Gate Threshold Voltage | 3V |
Maximum Power Dissipation | 60 W |
Transistor Configuration | Single |
Maximum Gate Source Voltage | +30 V |
Number of Elements per Chip | 1 |
Width | 2.4mm |
Height | 6.2mm |
Typical Gate Charge @ Vgs | 9.5 nC @ 10 V |
Series | MDmesh K5, SuperMESH5 |
Minimum Operating Temperature | -55 °C |
Length | 6.6mm |
Transistor Material | Si |
Maximum Operating Temperature | +150 °C |
