STE40NC60 N-Channel MOSFET, 40 A, 600 V MDmesh, SuperMESH, 4-Pin ISOTOP STMicroelectronics [STE40NC60]; 103-1568
0₫
Mã kho: 1031568
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Channel Type | N |
| Maximum Continuous Drain Current | 40 A |
| Maximum Drain Source Voltage | 600 V |
| Package Type | ISOTOP |
| Mounting Type | Panel Mount |
| Pin Count | 4 |
| Maximum Drain Source Resistance | 130 mΩ |
| Channel Mode | Enhancement |
| Maximum Gate Threshold Voltage | 4V |
| Minimum Gate Threshold Voltage | 2V |
| Maximum Power Dissipation | 460 W |
| Transistor Configuration | Single |
| Maximum Gate Source Voltage | -30 V, +30 V |
| Number of Elements per Chip | 1 |
| Series | MDmesh, SuperMESH |
| Maximum Operating Temperature | +150 °C |
| Length | 38.2mm |
| Typical Gate Charge @ Vgs | 307.5 nC @ 10 V |
| Height | 9.1mm |
| Transistor Material | Si |
| Width | 25.5mm |
| Minimum Operating Temperature | -65 °C |
