RSD100N10TL N-Channel MOSFET, 10 A, 100 V RSD100N10, 3+Tab-Pin SOT-428 ROHM [RSD100N10TL]; 133-2836
by ROHM
0₫
Mã kho: 1332836
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Channel Type | N |
| Maximum Continuous Drain Current | 0.416666666666667 |
| Maximum Drain Source Voltage | 100 V |
| Package Type | SOT-428 |
| Mounting Type | Surface Mount |
| Pin Count | 3 + Tab |
| Maximum Drain Source Resistance | 147 mΩ |
| Channel Mode | Enhancement |
| Maximum Gate Threshold Voltage | 2.5V |
| Minimum Gate Threshold Voltage | 1V |
| Maximum Power Dissipation | 20 W |
| Transistor Configuration | Single |
| Maximum Gate Source Voltage | -20 V, +20 V |
| Number of Elements per Chip | 1 |
| Width | 5.5mm |
| Forward Diode Voltage | 1.5V |
| Series | RSD100N10 |
| Height | 2.3mm |
| Typical Gate Charge @ Vgs | 18 nC @ 10 V |
| Maximum Operating Temperature | +150 °C |
| Transistor Material | Si |
| Length | 6.5mm |
