FQA46N15 N-Channel MOSFET, 50 A, 150 V QFET, 3-Pin TO-3PN ON Semiconductor [FQA46N15]; 145-5674
0₫
Mã kho: 1455674
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Channel Type | N |
| Maximum Continuous Drain Current | 50 A |
| Maximum Drain Source Voltage | 150 V |
| Package Type | TO-3PN |
| Mounting Type | Through Hole |
| Pin Count | 3 |
| Maximum Drain Source Resistance | 42 mΩ |
| Channel Mode | Enhancement |
| Minimum Gate Threshold Voltage | 2V |
| Maximum Power Dissipation | 250 W |
| Transistor Configuration | Single |
| Maximum Gate Source Voltage | -25 V, +25 V |
| Number of Elements per Chip | 1 |
| Width | 5mm |
| Minimum Operating Temperature | -55 °C |
| Transistor Material | Si |
| Height | 20.1mm |
| Series | QFET |
| Maximum Operating Temperature | +175 °C |
| Length | 15.8mm |
| Typical Gate Charge @ Vgs | 85 nC @ 10 V |
