FFSP1665A SiC MOSFET, 2+Tab-Pin TO-220-2L ON Semiconductor [FFSP1665A]; 172-3393
0₫
Mã kho: 1723393
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Package Type | TO-220-2L |
| Mounting Type | Through Hole |
| Pin Count | 2 + Tab |
| Maximum Power Dissipation | 150 W |
| Transistor Configuration | Single |
| Number of Elements per Chip | 1 |
| Transistor Material | SiC |
| Forward Diode Voltage | 2.4V |
| Length | 10.36mm |
| Maximum Operating Temperature | +175 °C |
| Minimum Operating Temperature | -55 °C |
| Height | 15.21mm |
| Width | 4.67mm |
