FDS5351 N-Channel MOSFET, 6.1 A, 60 V PowerTrench, 8-Pin SOIC ON Semiconductor [FDS5351]; 166-3360
0₫
Mã kho: 1663360
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Channel Type | N |
| Maximum Continuous Drain Current | 6.1 A |
| Maximum Drain Source Voltage | 60 V |
| Package Type | SOIC |
| Mounting Type | Surface Mount |
| Pin Count | 8 |
| Maximum Drain Source Resistance | 58.8 mΩ |
| Channel Mode | Enhancement |
| Minimum Gate Threshold Voltage | 1V |
| Maximum Power Dissipation | 5 W |
| Transistor Configuration | Single |
| Maximum Gate Source Voltage | -20 V, +20 V |
| Number of Elements per Chip | 1 |
| Length | 4.9mm |
| Minimum Operating Temperature | -55 °C |
| Transistor Material | Si |
| Width | 3.9mm |
| Typical Gate Charge @ Vgs | 19 nC @ 10 V |
| Height | 1.57mm |
| Series | PowerTrench |
| Forward Diode Voltage | 1.3V |
| Maximum Operating Temperature | +150 °C |
