FDA70N20 N-Channel MOSFET, 70 A, 200 V UniFET, 3-Pin TO-3PN ON Semiconductor [FDA70N20]; 759-8920
0₫
Mã kho: 7598920
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Channel Type | N |
| Maximum Continuous Drain Current | 70 A |
| Maximum Drain Source Voltage | 200 V |
| Package Type | TO-3PN |
| Mounting Type | Through Hole |
| Pin Count | 3 |
| Maximum Drain Source Resistance | 35 mΩ |
| Channel Mode | Enhancement |
| Minimum Gate Threshold Voltage | 3V |
| Maximum Power Dissipation | 417 W |
| Transistor Configuration | Single |
| Maximum Gate Source Voltage | -30 V, +30 V |
| Number of Elements per Chip | 1 |
| Transistor Material | Si |
| Maximum Operating Temperature | +150 °C |
| Minimum Operating Temperature | -55 °C |
| Length | 15.8mm |
| Width | 5mm |
| Series | UniFET |
| Height | 20.1mm |
| Typical Gate Charge @ Vgs | 66 nC @ 10 V |
