IRF9410TRPBF N-Channel MOSFET, 7 A, 30 V IRF9410, 8-Pin SO Infineon [IRF9410TRPBF]; 162-3278
by Infineon
0₫
Mã kho: 1623278
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Channel Type | N |
| Maximum Continuous Drain Current | 0.291666666666667 |
| Maximum Drain Source Voltage | 30 V |
| Package Type | SO |
| Mounting Type | Surface Mount |
| Pin Count | 8 |
| Maximum Drain Source Resistance | 50 mΩ |
| Channel Mode | Enhancement |
| Minimum Gate Threshold Voltage | 1V |
| Maximum Power Dissipation | 2.5 W |
| Transistor Configuration | Single |
| Maximum Gate Source Voltage | ±20 V |
| Number of Elements per Chip | 1 |
| Forward Diode Voltage | 1V |
| Series | IRF9410 |
| Height | 1.5mm |
| Width | 4mm |
| Typical Gate Charge @ Vgs | 18 nC @ 10 V |
| Length | 5mm |
| Minimum Operating Temperature | -55 °C |
| Maximum Operating Temperature | +150 °C |
